Easytork Pneumatic 1/4 Turn Vane Actuators

Easytork's patented spring-less internal air resevoir pneumatic vane actuator is the world's smallest and lightest pneumatic actuator for fail-safe and one of the most efficient actuators in the market.

Compared to a spring & diagphram actuator for control valves, our patented control actuator is 1/10th the weight, 1/6th the size, uses 1/4th of air, has better than/equal to benchmark test performance, and is significantly more cost effective.

ECA Series
The PREMIER Control Valve Actuator

EVA Series
On/Off Solutions-Oriented Actuator

Harsh, Corrosive, Dirty Environment Case Study:

How Easytork actuators thrived in a challenging actuation application while reducing total cost of ownership by over 77% for a mining operator

Read Case Study

Footprint Reduction Case Study:

How Easytork compact actuators significantly reduce valve actuation footprint in skids and mobile units

Read Case Study

Water Industry Case Study:

Using water to drive the Easytork actuator

Read Case Study

When to use Easytork for valve automation? When SOLUTIONS are required.

One-stop shop for control valve and on/off valve actuation High cycle applications
Most compact, lightest, least air consumption pneumatic actuator in the world (40+% smaller, 50+% lighter than rack & pinions) Longevity in harsh dirty environments
Actuator precise throttling of <0.05% repeatability (ECA Series) Easiest actuator to direct mount to ball valves and butterfly valves
Multiple functions in one unit: convert between double-acting and fail-safe, and fail-open and fail-close (<60 sec) 0% side loading to improve valve life cycle
AWWA C541 compliant 2-year / 2-million cycle warranty

PRODUCT LINE


ECA Series (Easytork Control Actuator)


EVA Series (Easytork Vane Actuator)


ECA Series Actuators

+ THE PREMIER control valve solution
+ At <0.05% repeatability, Easytork Control Actuator is better than/equal to spring & diaphragm actuators for control valves
+ Direct mount across all control valve brands, including control valves with splined shafts
+ 1/10th the weight, 1/6th the size of spring & diagraphram actuators
+ Signficantly more cost effective and up to 75% more air efficient than spring & diaphragm actuators
+ Patented vane actuator with an integral air reservoir eliminates the need for springs and exponentially increases the efficiency and relability of actuation
EVA Series Actuators

+ The problem solver for on/off applications
+ World's smallest and lightest pneumatic actuators for fail-safe
+ Easy direct mount to most ball valves and butterfly valves
+ Requires the least air consumption in the world
+ Basic control valve solution at 0.50% repeatability
+ Max size up to 24,411 in-lb @ 80 psi /45,770 in-lb @ 150psi
+ American Water Works Association (AWWA) C541 compliant


Accessories / Ancillaries to Complete Your Valve Automation Needs


Easytork Solenoid Valve (ESV)

Patented solenoid valve covers a full range of applications including NEMA 4, Ex-Proof, ATEX EX, I-Safe, Low-Temp, and Low Power. From 24VDC, 120 VAC, and 240 VAC.

Easytork Air Pilot Valve (EPV)

Even with a third party solenoid valve, users can convert EVA double-acting actuator to fail-safe through Easytork's patented air pilot valve.

Easytork Namur Trip Valve (NTV)

Installing or not installing Easytork’s NTV with a double-acting positioner determines what function (fail-safe, in open or close, or double-acting) the actuator has. Any 4-20ma or 3-15 psi double acting positioner in the market works with the system.

Limit Switches

Easytork offers a full range of NEMA 4 and explosion proof applications.

Lockout & Partial Stroke Test

Integral add on to EVA actuators without adding hysteresis to valve connection.

Declutchable Gear Operator (Updated May '19)

High strength and high torque.

Mounting Hardware

When direct-mount is not an option, our adaptable shafts, drive inserts, and brackets eliminate need for couplers and their associated costs and mechanical issues. Easytork mounting hardware will not cause stem side loading and protects actuator valve stem from leakage.

Easytork is the proud recipient of the Frost & Sullivan New Product Innovation Award in the pneumatic actuators market

More Information

Featured in



ABOUT EASYTORK AUTOMATION


Headquartered in St. Louis, Missouri, Easytork manufactures quarter turn pneumatic actuators for users worldwide in a wide variety of markets such as oil & gas, chemical, aerospace, power generation, water/municipal, general industrial, etc. Our patented spring-less internal air reservoir vane design makes our pneumatic actuator the smallest and lightest in the world. Additionally, compared to spring & diaphragm for control valves, our patented control actuator line is 1/10th the weight, 1/6th the size, significantly more cost effective and air efficient, has better than/equal to benchmark test performance, and is more robust and easier to install. Easytork is the new generation of actuation innovation - our products are proudly designed with process users in mind first and foremost, with the vision of simplifying process controls and generating impactful savings and efficiencies at their facilities.

Easytork is the 2013 Arch Grant recipient, the 2015 second place recipient of the Accelerate St. Louis Challenge (St. Louis Economic Development Partnership), and a 2015 Bright Futures recipient.

“The introduction of the pneumatic fail-safe actuator without the use of springs, external reservoirs, has significantly changed the pneumatic fail-safe industry. This technology is in line with the global trend towards advancement in durability, safety, efficiency and cost of pneumatic actuators.” - As featured in Valve World Magazine, Special Topic
